Embedded systems are widely regarded as controllable systems that integrate both hardware and software components, offering high reliability and real-time performance. These systems are specifically designed to meet precise engineering requirements, which often include constraints on cost, size, and power consumption. To achieve these goals, developers tailor both the hardware and software elements of the system accordingly. Developing embedded systems requires specialized tools and integrated development environments (IDEs), such as IAR, along with a cross-compilation process between the host computer and the target embedded board.
The hardware of an embedded system typically includes an embedded processor, memory, and peripheral devices. Common types of embedded processors are microcontrollers (MCUs), microprocessors (MPUs), and digital signal processors (DSPs). As the core component, the advancement in embedded processor technology directly influences the functionality and application capabilities of the final product.
On the software side, embedded systems consist of three main layers: the operating system, middleware, and application software. The embedded operating system manages resource allocation and task scheduling, while middleware provides tools and support for application development. The application software is specifically developed based on the hardware platform to meet the needs of a particular project.
In recent years, with the rapid expansion of highway networks and urban rail transit, the demand for intelligent transportation systems has grown significantly. LED displays play a crucial role in these systems by providing real-time traffic updates, helping drivers make informed route choices and reducing congestion. This improves overall traffic efficiency and optimizes traffic flow distribution.
In the field of intelligent transportation, LED display systems are designed to receive real-time traffic information from a central control center through host software. This data is then displayed on LED screens at traffic sites, guiding vehicles effectively. At the same time, the local control system sends back live traffic data to the central management, allowing for real-time monitoring and adjustment of display operations.
Traditional LED control systems often relied on a minimal setup using a single-chip microcontroller, flash memory, and static RAM. However, as embedded technology advanced and the need for more complex functions increased, the limitations of single-chip systems became evident. These systems could no longer meet the growing market demands.
To address these challenges, modern LED control systems now use powerful platforms like ARM and FPGA. In this design, the ARM handles communication between the upper computer and the LED control system, while the FPGA manages the dynamic scanning of the display. This approach enhances performance and flexibility.
Communication between the central control system and the LED display can be achieved through various methods, including standard serial communication (RS232, RS485), Ethernet (LAN), fiber optics, and even wireless transmission. These options ensure reliable and efficient data exchange in diverse environments.
